Orbital Welding

Matini Technology owns Arc Machine Incorporated (AMI) 207 and 307 Model welding plants. All include their own welding heads and collets, enabling Matini to work at multiple 'clean room' sites simultaneously. Each item is regularly calibrated and serviced to ensure that Matini supplies authentic certification in all supporting documentation for every welding project.

Cooling Unit Attaches to the base of Model 207 or 227 power supply and features a heavy duty pump, flow sensor and an ultra-violet water purifier. Powered by an outlet in the mating power supply, it provides a recirculating coolant source for water-cooled weld heads, allowing welding of heavy-wall tube or high-duty cycle welding.

External Memory Module Stores up to 100 weld schedules (in non-volatile memory) for safe-keeping or transfer of weld schedules between machines.

Remote Operator's Pendant Allows remote operation of power supply controls for: weld/test mode; sequence start/stop; manual purge; motor jog; print; weld schedule access; amps up/down; and all-stop. It comes with a 25ft (8m) cable and additional extension cables are also available.

Tungsten Electrodes Matini's own precision ground, cut-to-length electrodes increase weld repeatability and last longer than those not machined to the same exacting standards. These electrodes are constructed from non-radioactive Sylvania 2% ceriated Tungsten.

Off-set Electrode Holders (Mushroom) Reposition the electrode axially from the centre of the weld head closer to one side, thereby reducing the stick-out length of fittings and valves. A simple solution for difficult applications, the holders are available in 90° (fixed) and adjustable angles.
